MPPT Solar Controller EPSOLAR Tracer Series 20A
This Solar Regulator adopts MPPT technology (Maximum Power Point Tracking). This advanced tracking algorithm makes the solar module operate at an ideal voltage where the solar modules can produce the maximum available power. Compared to conventional PWM controllers, MPPT technology increases the charge efficiency by up to 30% and decreases the power of solar array needed. It can also accuratley track the MPP point in any situation which will improve energy efficiency and obtain maximum solar energy.
The regulator has the ability to step-down the higher voltage solar array to recharge a lower voltage battery bank. This allows on grid solar modules or thin film modules to charge the off-grid battery, and the cable size can be reduced because of the small current from the solar array. Based on common positive design and advanced MPPT control algorithm, with LCD displaying running status, this product is artistic, economical and practical.
EPSOLAR Tracer Series 20A Features:
- Advanced MPPT technology
- High tracking efficiency no less than 99.5%
- Peak conversion efficiency of 98%
- Ultra-fast tracking speed
- Accurately recognizing and tracking of multiple power point
- Multi-function LCD displays system information intuitively
- User programmable for battery types, load control etc.
- 3-Stage charge with PWM output
- Common positive grounding design
- RS485 port with industrial standard MODBUS open architecture
- Fully programmable function via PC software or remote meter
Solar Regulator Features:
- Excellent thermal design and natural air cooling
- Full power output in ambient temperatures up to 45oC
- Temperature compensation function
- Sealed, Gel, Flooded battery type options
- CE and RoHS certificate
- PV reverse polarity protection
- PV short circuit protection
- PV over current alarm protection
- Battery overcharge protection
- Battery over discharge protection
- Battery reverse polarity protection
- Load short circuit protection
- Controller overheating protection
Maximum power point tracking solar charge controller for off-grid & remote power solutions. With MPPT control algorithm, in any situation, this product can fast and accurately track out the best maximum power point (MPP) of photovoltaic array, in order to obtain the maximum solar energy in time, which remarkably improves energy efficiency.
20A Tracer MPPT Solar Charge Controller Regulator has a rating of 4.50/5 based on 2 reviews.
Solar charge controller regulator
So far so good. Testing at home. Haven't gone camping yet but am sure will be a huge improvement to what I have now. Thank you for your prompt deliveryMinke K on 6 September 2017
I UPGRADED MY OLDER VERSION OF SOLAR CONTROLLER TO MPPT. THE DIFFERENCE WAS VERY NOTICABLE IN A SHORT PERIOD OF TIME. VERY HAPPY WITH THE RESULTS. THANKYOU. DAVE RICHARDSDavid R on 31 May 2017
|EPSolar 20A MPPT Regulator|
|Nominal system voltage||12/24VDC Automatic|
|Rated charge current||20A|
|Rated discharge current||20A|
|Battery input voltage range||8~32V|
|Max. PV open circuit voltage||100V(at minimum operating environment temperature)
92V(at 25℃ environment temperature)
|MPP voltage range||VBAT +2V～ 72V|
|Max PV input power||12V system 260W
24V system 520W
|Equalize charging voltage||Sealed: 14.6V,
|Boost charging voltage||Gel: 14.2V
|Float charging voltage||13.8V|
|Low voltage reconnect voltage||12.6V|
|Low voltage disconnect voltage||11.1V|
|Self consuption||≤20mA/12V; ≤16mA/24V|
|Temperature compensation coefficient||-3mV/ ºC/2V(25 ºC)|
|Dimensions||220mm x 154mm x 52mm|
|Working temp.||-25oC ~ +45oC|
