Overview
Watt & Power Meter for use with Solar Panels. (Now with Bonus x 2 extra Anderson Plugs)
Do you want to know exactly how much power your solar panel is producing? It's often been difficult to measure this without special equipment or expert knowledge. However, our Watt & Power Meter is a simple yet extremely handy device that gives a digital display of exactly how much charge your panels are actually producing. This Watt Meter is easily installed and provides you with all the key ratings of your solar panels in real-time. This is a perfect companion to our range of Portable Solar Panels, but can be used with any type of solar panel setup. Installation is so easy as our Watt Meter has two Anderson plugs, and is installed in-line between your solar regulator and batteries/load. Simply connect the solar panel regulator's output to the labelled "source" side of the watt meter, and connect the battery/load cabling to the "load" side. Once there is power flowing through the Watt Meter, the device will initialise and show you a full range of ratings including:
- Current (Amps/A) at the present moment
- Voltage (Volts/V) at the present moment
- Power (Watts/W) at the present moment
- Total Amps (Amp hours/Ah) since device initialised
- Total Power (Watt hours/Wh) since device initialised
- Highest Voltage Maximum (Vm) since device initialised
- Highest Power Peak (Watt Peak/Wp) since device initialised
- Highest Current Peak (Amp Peak/Ap) since device initialised
Our Solar Watt Meter only requires a tiny 7mA draw to operate, so there will be no significant reduction in your power production during usage. This Watt Meter is especially useful to measure the power consumption of your 12volt fridge over time, say for a 24-hour period, as the fridge cycles on and off to maintain a set temperature. A Watt Meter can also be used to monitor the output of your solar panel over the course of a day. Aussie Batteries and Solar are experts in Watt Meters and ours have been custom assembled to include 50 Amp Anderson plugs, ideal for the 4WD and Camping and Caravanning enthusiast. The Anderson plugs are installed at our factory and you can leave them installed, or if you would like a modification give us a call and speak to us about installing a connector of your choice. These Watt Meters can also be hard-wired into a vehicle or camper trailer. Why not speak to us about what configurations will work for you as we are happy to customise for your needs.
Reviews
150A Solar Watt Meter (includes bonus 2x anderson plugs) has a rating of 4.64/5 based on 86 reviews.
Good investment
Very handy to see what my system is doing without a multi meter. just buy it. Staff are on the ball.I emailed with issue and they actually rang me to sort out... great customer service.
Anonymous on 4 March 2022
Battery
Great service an quick delivery
Lyndal W on 4 February 2022
Solar watt meter
Easy little gadget, easy to use and read. With the rain and poor weather, keeping an eye on power use and generation has been a big help. For an extra few dollars, buying this one from Aussie batteries rather than ebay or similar places I know it has a genuine warrantee and is backed by a real business.
Lyndissi E on 5 January 2022
Lloyd
The meter was but one of my purchases and like the remainder, was true to form and specs. The absolute best thing Aussie Batteries and Solar is the service, if you have any issue, email them and they will be back to you immediately and at times by phone to sort any delivery issue out in person. That is not a service that is widely available, and it was the service that was outstanding as the products. I highly recommend them.
Lloyd C on 4 January 2022
Watt meter
It does everything they say it does, it's a handy little bit of kit
Daniel S on 3 December 2021
Specifications
| 150A Solar Watt Meter Specifications | |
|---|---|
| Safe Operating Voltage | 0V - 60V |
| Safe Operating Current | 0 - 100A Intermitten 50A Continuous Note: this assumed the device's writes are in free air, and attached to connections at or below temperature of 35 |
| Nominal Operating Conditions | 0 Note: Max temperature must be reduced at max current rating. |
| Measurement Update Period | 400 mS |
| Data Queue Sequence Time | 2 seconds |
| In Circuit Resistance | 0.001 Ohms |
| Operation Current | 7mA |
| Auxiliary Power Voltage | 4.8V - 60V eg. from a receiver battery |
| Dimensions | Approx. 200mm L x 42mm W x 25mm D (including anderson plugs) Approx. 85mmL x 42mmW x25mmD (only watt meter unit) |
| Weight | Approx 130g |
| Display Screen | 16 Character x 2 row STN LCD |
| Solar Watt Meter Measurement Parameters | |
|---|---|
| Voltage | 0 - 60V, 0.01V Resolution Note: 0V min. w/auxiliary power, eg. a receiver battery. Otherwise, 4.0V |
| Current | 0 - 150A peak, 0.01A Resolution Note: 65A continuous |
| Power | 0 - 9000W, 0.1W Resolution |
| Charge | 0 - 65AH, 0.001Ah |
| Energy | 0 - 9000Wh, 0.1Wh Resolution |
